PE Layflat Hose for Water Transfer Through the Weave High Tensile Strength
Product Specification
| Backflex™ TPE-P Layflat Flexible Pipe |
| ID | Wall Thickness | Weight | Working Pressure | Bursting Pressure |
| Inch | mm | Inch | mm | lbs/ft | kg/m | PSI | bar | PSI | bar |
| 2 | 52+1.5 | 0.1 | 2.4 | 0.35 | 0.52 | 300 | 21 | 900 | 63 |
| 3 | 77+2.0 | 0.1 | 2.5 | 0.61 | 0.9 | 250 | 17 | 750 | 51 |
| 4 | 104+2.0 | 0.13 | 3 | 0.89 | 1.33 | 250 | 17 | 750 | 51 |
| 6 | 155+2.5 | 0.15 | 3.8 | 1.6 | 2.38 | 200 | 14 | 600 | 42 |
| 8 | 204.3.0 | 0.17 | 4.3 | 2.17 | 3.23 | 200 | 14 | 600 | 42 |
Product Application
Long Distance Fresh Water Transfer
Mining Dewater Soluiongs
Flowback Water Transfer Solutions
Pipe rehabilitation
By-pass Water Transfer Solution
Product Introduction
Backflex is one type of through-the-weave TPE-P covered hose which is made of TPE-P materials approved according to NSF 61 standard.
Backflex hoses shall be made from 100% high tenacity virgin synthetic yarn circular woven and completely, totally embedded in the TPE-P compound, excellent protected against mechanical damage, forming a single homogenous construction without the use of any glues or adhesives of any type.
Backflex performs excellently in age-resistance. It is theoretically supposed to be used for 30-50 years.
Backflex is a press-flat hose and can keep round shape under the condition of no pressure. Backflex hoses can be pressed flat and can be easily laid down and retrieved as layflat hoses.
♦ Extra abrasion resistance for rugged terrain and extreme conditions
♦ Puncture resistant
♦ Chemicals resistant
♦ UV resistant
Product Features
Inner tube and cover: Smooth TPE-P cover and tube.
Reinforcement: Circular woven polyester jacket
Operating Temperature Range: From -60° F to 176° F(-50° C to 80° C)
Standard Color: Blue, black, other colors available per request
Standard Length: 300ft/91.5m, 330ft/100m, 660ft/200m; other lengths available per request;
Couplings: Storz couplings, Camlocks etc.
